Pouch Cell Secondary Vacuum Hot Sealing Machine
Product Details
STC-BEF-300 vacuum sealer is used for pouch cell secondary hot sealing after electrolyte filling and battery formation. It is equipped with auto piercing needle for de-gassing the cell and do a secondary sealing under vacuum condition. 300mm Copper sealing blade, touch screen controlled with high automation.
Key Features
• It has the piercing needle, piercing function can be completed autoamtically.
• 300mm width copper sealing blade with good heating conduction.
• Sealing pressure of upper and lower sealing blade can be adjusted.
• Upper and lower sealing blade temperature can be controlled separated and settable, digital display by thermostat.
• Two start buttons for avoiding hand injured, the lid can go down only by pressing the strat bottons at the same time.
• Touch screen operation, high automation.
• Sealing time cna be set.
• Perspective window for obseving it conveniently during working.
• The lid will open automatically when finish sealing.
Technical Parameters
| Model |
STC-BEF-300 |
| Working voltage |
AC110V/220V optional |
| Sealing blade length |
300mm copper sealing balde, customized size is available |
| Sealing balde width |
5mm, customized size is available |
| Upper sealing blade temp |
RT~250℃ adjustable |
| Lower sealing blade temp |
RT~250℃ adjustable |
| Sealing temp accuracy |
±2℃ |
| Sealing time |
0~99s adjustable |
| Heating sealing pressure |
0.5~0.7MPa |
| Power |
1000W |
| Dimension |
L500 * W500 * H700mm |
| Weight |
80kg |
Warranty
1 year warranty with lifetime support. Man-made damage is not covered.
FAQ
1. Are you a manufacturer?
A: Yes, our factory is located in Shenzhen, China.
We have more than 10 Year experience for manufacturing battery lab research equipment. We own a professional R&D department.
2. Do you accept customized product?
A: Yes, most of our products can be customized to meet different requirements.
3. Will you provide test video before dispatch?
A: Yes, we take test video for every equipment before dispatch, which will display how to use it.
4. Can you offer overseas installation service?
A: Yes, we can dispatch professional engineer for on-site installation service.
Product Tags:
|
|
300mm Pouch Cell Final Vacuum Sealing Machine With Auto Piercing Images
|
